SFD-700The type of SFD-700 multi-channel sound and light alarm
(1).png){kind=small}
Notable features:the combination of flexible,easy installation,alarm clear,cost-effective.
Measuring range (Range):0-100% LEL.
Controller Power:input AC220V±10%,50/60HZ;output DC24V;
Power consumption:<4W/channel.
Alarm response time:<20 seconds.
Fuse rating:1A.
- Product feature
- Performance parameter
- Data download
- Operation video
Notable features: the combination of flexible, easy installation, alarm clear, cost-effective.
Measuring range (Range): 0-100% LEL.
Controller Power: input AC220V ± 10%, 50 / 60HZ; output DC24V;
Power consumption: <4W / channel.
Alarm response time: <20 seconds.
Alarm set value: 10-30% LEL (adjustable).
Alarm accuracy: ± 5%.
Temperature range: -10-45 ℃.
Humidity range: 20-90% RH.
Pressure range: standard atmospheric pressure ± 10%.
Related equipment: SFD-600 (BK) combustible gas detector.
Assembly specifications:two, four, eight, ten channel.
 |
 |
 |
 |
 |
 |
 |
|
| SFD-300 gas alarm controller |
